PV Panel I-V and P-V Curves at STC and Under Shading

About this model

I-V and P-V curves for four different panels, at standard test conditions and with shading applied. The shaded curves grow the second hump that makes a naive hill-climbing tracker settle on the local maximum and lose most of the array — the failure that partial-shading papers exist to solve.
